Description

Description

This series of filling machines has a simple and reasonable structure, high accuracy, and more convenient operation. Suitable for daily chemical, food, pesticide and special industries, it is an ideal equipment for filling high viscosity fluids and ointments. Reasonable design, compact model, convenient operation, with a filling volume adjustment handle, filling speed can be adjusted at will.Driven by a cylinder and piston made from materials with one-way valves control the flow of materials and also magnetic reed switch control cylinder itinerary can control the filling volume.

Technical Parameters

Model :G4WG10-100ml
Voltage supply :220/110V 50/60Hz
Power :100W
Filling accuracy :≤±1%
Filling speed :About 30-60bottles/min
Filling volume :10-100ml/30-300ml/50-500ml/100-1000ml/500-3000ml/1000-5000ml
Air pressure :0.4-0.6MPa
Size of air compressor connector :OD8mm
Air consumption :≥0.1m³/min
Size :1310*1010*420mm

Weight :90kg

Application

Widely used in the filling of various liquids,beverages,pastes,cream and various granule-containing materials,such as juice,oil,milk,honey,lotion,jams,cream,ketchup,chili sauce,etc

Detail Images
